Pixelaria

🚀 Live Demo

A simple pixel editor web application that allows users to create and edit pixel art using a grid-based interface. This application is under development.

Table of Contents

• Overview
• Current Status
• Planned Features
• Recent Improvements
• Installation
• Running Tests
• License
• Contact

Overview

This project aims to provide a user-friendly interface for creating pixel art, with features such as undo/redo functionality, color selection, pixel manipulation and basic tools (pencil, eraser, line, bucket). The application has been refactored to improve modularity, maintainability and scalability by introducing:

Managers

• ToolManager: Oversees tool functionalities and interactions.
• LayerManager: Manages layers and their properties (Will be supported for UI soon).

Generic Systems

• HistorySystem: Manages records in history buffer for undo/redo operations.
• ChangeSystem: Manages and records changes done to a collection of data, storing it before and after states.

General Services

• Color: Manages and caches all used colors in application, and provide color manipulation utilities.
• EventEmitter: Manages interactions between UI components and the application core logic.
• PixelChange: Specification of ChangeSystem class for pixel manipulation.

Tools

• ToolService: Manages services for tools. Composing various tools from collections of services allowing scalability.
• ServiceConfig: Manages configuration of tool services.

UI Components

• Allowiing interactions with the core logic.

Current Status

• ✅ Robust undo/redo system
• ✅ scalable tool interfaces and services
• ✅ basic tools: pencil, eraser, line, bucket
• ✅ random
• 🚧 Layers (in progress)

Planned Features

• color picker, area selection, magic wand
• Export to GIF
• Editiable color palletes
• Responsive design

Recent Improvements

Performance Optimizations (v0.5)

• Undo/redo system now handles 1000-step actions 5x faster (384ms → 65ms)
• Caching pixel changes and used colors, reducing memory usage by 30%
• Reduced memory usage by 30% in history operations

Installation

To run the pixel editor locally, follow these steps:

1. Clone the repository:

   git clone https://github.com/Crypt212/pixelaria.git

2. Build the project:

   cd pixelaria
   npm install
   npm run build

3. Preview:

   npm run preview

Running Tests

To run the tests for the pixel editor locally, follow these steps:

    npm test

Note: Project still in development and tests are under construction.

License

This project is licensed under the MIT License - see the LICENSE file for details.

Contact

For questions or feedback, feel free to reach out:

• **Ahmed El-esseily** - [email protected]
