fix(export): restore graph.html for large graphs

graphify/cli.py

@@ -1831,22 +1831,19 @@ def dispatch_command(cmd: str) -> None:
         stages = _StageTimer(co_timing)
         print("Loading existing graph...")
         # Solution 3 (#1019): don't hard-exit on an oversized graph.json here.
-        # Core outputs (graph.json + GRAPH_REPORT.md) still get written; the
-        # graph.html render below falls back to the community-aggregation view
-        # (node_limit=5000) when over the cap.
+        # Core outputs (graph.json + GRAPH_REPORT.md) still get written. The
+        # visualization policy below uses its own node-count limit.
         from graphify.security import check_graph_file_size_cap as _check_cap
-        _over_cap = False
         try:
             _check_cap(graph_json)
         except ValueError:
-            _over_cap = True
             try:
                 _over_cap_bytes = graph_json.stat().st_size
             except OSError:
                 _over_cap_bytes = -1
             print(
                 f"warning: graph.json exceeds cap ({_over_cap_bytes} bytes); "
-                f"falling back to community-aggregation view (node_limit=5000)",
+                "continuing with best-effort visualization",
                 file=sys.stderr,
             )
         _raw = json.loads(graph_json.read_text(encoding="utf-8"))
@@ -2038,12 +2035,31 @@ def dispatch_command(cmd: str) -> None:
         # Snapshot BEFORE any artifact is replaced: GRAPH_REPORT.md was written
         # first, so the dated folder held the NEW report, not the previous (#2402).
         from graphify.export import backup_if_protected as _backup
+        from graphify.exporters.html import _HTML_STALE_MARKER
         _backup(out)
+        html_stale_marker = out / _HTML_STALE_MARKER
+
+        def _clear_html_stale_marker() -> None:
+            try:
+                html_stale_marker.unlink(missing_ok=True)
+            except OSError as exc:
+                print(
+                    "warning: graph.html stale marker could not be cleared; "
+                    f"regeneration may be retried: {exc}",
+                    file=sys.stderr,
+                )
+
+        stale_marker_preexisted = html_stale_marker.exists()
+        # Mark before graph.json advances. Report/sidecar generation or process
+        # interruption must not leave an older HTML looking current.
+        html_stale_marker.touch()
         # The #479 guard can refuse this write, so it goes before the sidecars —
         # a report and labels describing a clustering graph.json does not contain
         # are worse than no run at all (#2436).
         if not to_json(G, communities, str(out / "graph.json"),
                        community_labels=labels, built_at_commit=_commit):
+            if not stale_marker_preexisted:
+                _clear_html_stale_marker()
             print(
                 "graph.json NOT written: refusing to overwrite (see warning above). "
                 "GRAPH_REPORT.md, .graphify_labels.json and .graphify_analysis.json "
@@ -2092,22 +2108,46 @@ def dispatch_command(cmd: str) -> None:
         if no_viz:
             if html_target.exists():
                 html_target.unlink()
+            _clear_html_stale_marker()
             stages.mark("export"); stages.total()
             print(f"Done - {len(communities)} communities. GRAPH_REPORT.md and graph.json updated (--no-viz; graph.html removed).")
         else:
+            html_written = False
+            skip_reason: str | None = None
             try:
-                # Over-cap fallback (#1019): force the community-aggregation
-                # path so an oversized graph still renders a usable graph.html.
-                _node_limit = 5000 if _over_cap else None
-                to_html(G, communities, str(html_target), community_labels=labels or None,
-                        node_limit=_node_limit)
-                stages.mark("export"); stages.total()
-                print(f"Done - {len(communities)} communities. GRAPH_REPORT.md, graph.json and graph.html updated.")
+                from graphify.exporters.html import _viz_node_limit
+                viz_limit = _viz_node_limit()
+                if viz_limit <= 0:
+                    html_target.unlink(missing_ok=True)
+                    _clear_html_stale_marker()
+                    skip_reason = "GRAPHIFY_VIZ_NODE_LIMIT=0 disables HTML visualization"
+                else:
+                    # Passing the positive visualization limit explicitly selects
+                    # the community meta-graph when the full graph is too large.
+                    html_written = to_html(
+                        G,
+                        communities,
+                        str(html_target),
+                        community_labels=labels or None,
+                        node_limit=viz_limit,
+                    )
+                    if html_written:
+                        _clear_html_stale_marker()
+                    else:
+                        skip_reason = "no useful community aggregation could be generated"
+                        if html_target.exists():
+                            skip_reason += "; existing graph.html left unchanged"
             except ValueError as viz_err:
+                skip_reason = str(viz_err)
                 if html_target.exists():
-                    html_target.unlink()
-                print(f"Skipped graph.html: {viz_err}")
-                stages.mark("export"); stages.total()
+                    skip_reason += "; existing graph.html left unchanged"
+
+            if skip_reason:
+                print(f"Skipped graph.html: {skip_reason}")
+            stages.mark("export"); stages.total()
+            if html_written:
+                print(f"Done - {len(communities)} communities. GRAPH_REPORT.md, graph.json and graph.html updated.")
+            else:
                 print(f"Done - {len(communities)} communities. GRAPH_REPORT.md and graph.json updated.")

     elif cmd == "update":

graphify/exporters/html.py

@@ -5,12 +5,14 @@
 from pathlib import Path
 import html as _html
 from graphify.analyze import _node_community_map
+from graphify.paths import write_text_atomic
 import json
 import networkx as nx
 from graphify.security import sanitize_label


 MAX_NODES_FOR_VIZ = 5_000
+_HTML_STALE_MARKER = ".graph.html.stale"

 def _viz_node_limit() -> int:
     """Return the effective viz node limit, honoring GRAPHIFY_VIZ_NODE_LIMIT env var.
@@ -399,7 +401,7 @@ def to_html(
     member_counts: dict[int, int] | None = None,
     node_limit: int | None = None,
     learning_overlay: dict | None = None,
-) -> None:
+) -> bool:
     """Generate an interactive vis.js HTML visualization of the graph.

     Features: node size by degree, click-to-inspect panel, search box,
@@ -411,6 +413,9 @@ def to_html(

     If node_limit is set and the graph exceeds it, automatically builds an
     aggregated community-level meta-graph instead of raising ValueError.
+
+    Returns True when the output was written. Returns False when an aggregated
+    view would contain fewer than two communities and is intentionally skipped.
     """
     limit = node_limit if node_limit is not None else _viz_node_limit()
     if G.number_of_nodes() > limit:
@@ -433,7 +438,7 @@ def to_html(
                               relation=f"{w} cross-community edges", confidence="AGGREGATED")
             if meta.number_of_nodes() <= 1:
                 print("Single community - aggregated view not useful. Skipping graph.html.")
-                return
+                return False
             meta_communities = {cid: [str(cid)] for cid in communities}
             mc = {cid: len(members) for cid, members in communities.items()}
             # Remap hyperedges from semantic node IDs to community IDs
@@ -460,11 +465,13 @@ def to_html(
                         "nodes": comm_ids,
                     })
                 meta.graph["hyperedges"] = remapped
-            to_html(meta, meta_communities, output_path,
-                    community_labels=community_labels, member_counts=mc)
+            written = to_html(meta, meta_communities, output_path,
+                              community_labels=community_labels, member_counts=mc)
+            if not written:
+                return False
             print(f"graph.html written (aggregated: {meta.number_of_nodes()} community nodes, {meta.number_of_edges()} cross-community edges)")
             print("Tip: run with --obsidian for full node-level detail.")
-            return
+            return True
         raise ValueError(
             f"Graph has {G.number_of_nodes()} nodes - too large for HTML viz "
             f"(limit: {limit}). Use --no-viz, raise GRAPHIFY_VIZ_NODE_LIMIT, "
@@ -626,4 +633,5 @@ def _js_safe(obj) -> str:
 </body>
 </html>"""

-    Path(output_path).write_text(html, encoding="utf-8")  # nosec
+    write_text_atomic(output_path, html)
+    return True

graphify/watch.py

@@ -1001,6 +1001,88 @@ def _stabilize_rebuild_cwd(watch_path: Path) -> bool:
         return False


+def _reconcile_graph_html(out: Path, graph_data: dict) -> str | None:
+    """Reconcile missing, stale, or explicitly disabled HTML visualization.
+
+    The unchanged-topology update path deliberately avoids clustering and
+    rewriting core artifacts. HTML is independently derivable, so rebuild it
+    from the communities and names already stored in graph.json when absent or
+    marked stale by a prior failed render.
+
+    Returns ``"rendered"`` or ``"removed"`` when it changed the HTML state,
+    otherwise ``None``.
+    """
+    html_target = out / "graph.html"
+    from graphify.exporters.html import _HTML_STALE_MARKER, _viz_node_limit
+    stale_marker = out / _HTML_STALE_MARKER
+
+    def clear_stale_marker() -> None:
+        try:
+            stale_marker.unlink(missing_ok=True)
+        except OSError as exc:
+            print(
+                "[graphify watch] graph.html stale marker could not be cleared; "
+                f"regeneration may be retried: {exc}"
+            )
+
+    limit = _viz_node_limit()
+    if limit <= 0:
+        changed = html_target.exists() or stale_marker.exists()
+        html_target.unlink(missing_ok=True)
+        clear_stale_marker()
+        return "removed" if changed else None
+    if html_target.exists() and not stale_marker.exists():
+        return None
+
+    had_html = html_target.exists()
+
+    node_communities = _node_community_map(graph_data)
+    communities: dict[int, list[str]] = {}
+    for node_id, cid in node_communities.items():
+        communities.setdefault(cid, []).append(node_id)
+
+    labels: dict[int, str] = {}
+    for node in graph_data.get("nodes", []):
+        cid = node_communities.get(str(node.get("id")))
+        name = node.get("community_name")
+        if cid is not None and isinstance(name, str) and name:
+            labels.setdefault(cid, name)
+
+    try:
+        from graphify.export import to_html
+        from graphify.paths import load_node_link_graph
+
+        persisted_graph = load_node_link_graph(graph_data)
+        written = to_html(
+            persisted_graph,
+            communities,
+            str(html_target),
+            community_labels=labels or None,
+            node_limit=limit,
+        )
+    except Exception as exc:
+        if had_html:
+            print(
+                "[graphify watch] Stale graph.html left unchanged; "
+                f"regeneration will be retried: {exc}"
+            )
+        else:
+            print(f"[graphify watch] Missing graph.html could not be regenerated: {exc}")
+        return None
+
+    if not written or not html_target.exists():
+        if had_html:
+            print(
+                "[graphify watch] Stale graph.html left unchanged; "
+                "no useful community view was generated."
+            )
+        else:
+            print("[graphify watch] Missing graph.html has no useful community view; skipped.")
+        return None
+    clear_stale_marker()
+    return "rendered"
+
+
 def _rebuild_code(
     watch_path: Path,
     *,
@@ -1103,7 +1185,7 @@ def _rebuild_code(
         from graphify.cluster import cluster, remap_communities_to_previous, score_all
         from graphify.analyze import god_nodes, surprising_connections, suggest_questions
         from graphify.report import generate
-        from graphify.export import to_json, to_html
+        from graphify.export import to_json
         from graphify.security import check_graph_file_size_cap

         # Re-apply the excludes the initial extract recorded, so an update/watch/
@@ -1596,7 +1678,19 @@ def _failed(f: str) -> bool:
                 flag = out / "needs_update"
                 if flag.exists():
                     flag.unlink()
-                print("[graphify watch] No code-graph topology changes detected; outputs left untouched.")
+                html_action = _reconcile_graph_html(out, existing_graph_data)
+                if html_action == "rendered":
+                    print(
+                        "[graphify watch] No code-graph topology changes detected; "
+                        "regenerated missing or stale graph.html."
+                    )
+                elif html_action == "removed":
+                    print(
+                        "[graphify watch] No code-graph topology changes detected; "
+                        "removed graph.html because HTML visualization is disabled."
+                    )
+                else:
+                    print("[graphify watch] No code-graph topology changes detected; outputs left untouched.")
                 return True

         communities = cluster(G)
@@ -1717,6 +1811,10 @@ def _failed(f: str) -> bool:
                 failed_sources=failed_sources,
             ):
                 return False
+            from graphify.exporters.html import _HTML_STALE_MARKER
+            # Mark before graph.json advances so an interruption cannot leave a
+            # previous visualization looking current to the fast path.
+            (out / _HTML_STALE_MARKER).touch()
             from graphify.export import backup_if_protected as _backup
             _backup(out)
             graph_tmp.replace(existing_graph)
@@ -1744,40 +1842,13 @@ def _failed(f: str) -> bool:
         except Exception:
             pass

-        # to_html raises ValueError for graphs > the viz node limit.
-        # Wrap so core outputs (graph.json + GRAPH_REPORT.md) always land.
+        # Reconcile from the persisted graph. The stale marker was written
+        # before graph.json advanced, so a failed or interrupted atomic render
+        # remains retryable from the unchanged-topology fast path.
         html_written = False
         if not no_change:
-            html_target = out / "graph.html"
-            try:
-                to_html(G, communities, str(html_target), community_labels=labels or None)
-                html_written = True
-            except ValueError as viz_err:
-                # Over the cap. Deleting was defensible on its own — a kept
-                # graph.html would describe an older, smaller graph — but it
-                # leaves a project that crossed the threshold with no
-                # visualization at all, and the file is gone before the user
-                # sees the message. The export path (#1019) already re-renders
-                # the community-aggregation view in exactly this case, so do
-                # the same here: current AND present beats current OR present.
-                from graphify.exporters.html import _viz_node_limit
-                if html_target.exists():
-                    html_target.unlink()
-                limit = _viz_node_limit()
-                if limit <= 0:
-                    # GRAPHIFY_VIZ_NODE_LIMIT=0 means "no HTML viz" (CI runners),
-                    # so honour it rather than aggregating around it.
-                    print(f"[graphify watch] Skipped graph.html: {viz_err}")
-                else:
-                    try:
-                        to_html(G, communities, str(html_target),
-                                community_labels=labels or None, node_limit=limit)
-                        # The aggregator declines to write a single-community
-                        # graph, so trust the file rather than the call.
-                        html_written = html_target.exists()
-                    except Exception as fallback_err:
-                        print(f"[graphify watch] Skipped graph.html: {viz_err} "
-                              f"(aggregated view also failed: {fallback_err})")
+            html_action = _reconcile_graph_html(out, candidate_graph_data)
+            html_written = html_action == "rendered"

         # Regenerate callflow HTML if the user previously generated one —
         # opt-in by existence so users who never ran callflow-html aren't affected.
