feat: add Pinecone vector database driver - #115

Open
Siyet wants to merge 3 commits into
trunkfrom
15-pinecone-driver
Open

feat: add Pinecone vector database driver#115
Siyet wants to merge 3 commits into
trunkfrom
15-pinecone-driver

Conversation

@Siyet

@Siyet Siyet commented Apr 26, 2026

Copy link
Copy Markdown
Owner

Summary

  • Full PineconeDriver implementation using @pinecone-database/pinecone SDK — browse indexes and namespaces, query vectors by similarity, upsert/delete vectors, view index statistics
  • Integrated across all touchpoints: connection form (API key field, no host/port), driver factory, MCP standalone server, import service (DBeaver + DataGrip), tree view (namespace icon), webpack externals
  • Custom command syntax via parsePineconeCommand: QUERY <index> vector=[...] topK=N, UPSERT <index> id=... vector=[...], DELETE <index> ids=[...], STATS <index>, LIST <index>

Closes #15

Assumptions

  • API key stored as config.password. Pinecone uses API key auth with no username. The connection form shows a dedicated "API Key" field that maps to the password field internally, consistent with how Redis stores its password.
  • No host/port fields. Pinecone is a managed cloud service; the SDK resolves endpoints from the API key. The connection form hides host/port/SSL/proxy when Pinecone is selected.
  • Custom command parser, not SQL. Like Redis, Pinecone doesn't use SQL. The execute() method parses a custom syntax: COMMAND index-name key=value .... JSON arrays/objects in params are supported for vectors, metadata, and filters.
  • Lazy require. The @pinecone-database/pinecone SDK is loaded via lazy require() to avoid blocking extension activation, following the same pattern as other drivers.
  • Icon uses next available font character. \E005 is used for the viewstor-pinecone icon in the existing viewstor-icons.woff2 font. If the glyph doesn't exist yet, the icon will fall back to the default; the font file needs a corresponding glyph added separately.
  • No Grafana export. Pinecone has no Grafana datasource plugin, so it's excluded from DB_TYPE_TO_GRAFANA_DS.
  • No safe mode. Pinecone doesn't support EXPLAIN, so safe mode checks are not applicable (the existing isSafeModeDB check already excludes unknown types).
  • Mock-based tests only. No free tier suitable for CI; unit tests cover the command parser (12 tests) and driver contract verification.

Manual test cases

  • Golden path: Add Connection → select "Pinecone" → enter API key → Test Connection → Save → expand tree (indexes with dimension/metric detail, namespaces with vector counts) → click an index → Result Panel shows id/values/metadata columns
  • Query vectors: Open query editor on Pinecone connection → QUERY my-index vector=[0.1,0.2,0.3] topK=5 → results show id, score, truncated values, metadata JSON
  • Upsert: UPSERT my-index id=test-1 vector=[0.1,0.2] metadata={"key":"val"} → success message
  • Delete: DELETE my-index ids=["test-1"] → success message with count
  • Stats: STATS my-index → table with total vectors, dimension, metric, namespaces, index fullness
  • List: LIST my-index namespace=ns1 prefix=doc_ limit=10 → list of vector IDs
  • Read-only mode: Mark connection read-only → upsert/delete should fail at the host level (readonly check)
  • Invalid command: SELECT * FROM my-index → error message with supported command syntax
  • MCP: add_connection with type: "pinecone", password: "<api-key>" → connection created successfully

Checklist

  • README — added Pinecone row to Supported Databases table
  • CHANGELOG — added entry under [Unreleased] > Added
  • CLAUDE.md — updated "What is Viewstor", Drivers list, Key Conventions with Pinecone-specific notes
  • l10n — extension description includes Pinecone
  • Wiki — new Pinecone driver section (note: cannot push wiki from PR)

Generated by Claude Code

claude added 3 commits April 26, 2026 05:25
Closes #15

Full PineconeDriver implementation using @pinecone-database/pinecone SDK.
Integrated across connection form, driver factory, MCP server, import
service, tree view, and driver contract tests.

- Schema: indexes as tables, namespaces as children with vector counts
- Custom command syntax: QUERY, UPSERT, DELETE, STATS, LIST
- Connection form: API key field, no host/port
- Optional methods: getEstimatedRowCount, getTableStatistics
- 12 unit tests for command parser, driver contract tests updated
…ands

The regex-based parser truncated nested JSON values like
filter={"$and":[{"a":1},{"b":2}]} at the first closing brace.
Replace with a bracket-counting parser that handles nested structures
and string escaping within JSON.

https://claude.ai/code/session_01RwjTCNaBKhphYNzopBwqK1
isReadOnlyQuery() only recognized SQL verbs, blocking all Pinecone
commands (QUERY, STATS, LIST) on read-only connections via MCP.
Add Pinecone read verbs to READ_VERB_RE and update the error message.

https://claude.ai/code/session_01RwjTCNaBKhphYNzopBwqK1

@Siyet Siyet left a comment

Copy link
Copy Markdown
Owner Author

Choose a reason for hiding this comment

The reason will be displayed to describe this comment to others. Learn more.

Fixes pushed

  • 8d85d6e — Replace regex-based param parser with bracket-counting parser that handles nested JSON (e.g. filter={"$and":[{"a":1},{"b":2}]}). Added 2 test cases.
  • d55e08e — Add Pinecone read commands (QUERY, STATS, LIST) to READ_VERB_RE so read-only connections can execute them via MCP. Updated error message. Added 3 test cases.

Issues to address

  • src/drivers/pinecone.ts:1 — Top-level import { DatabaseDriver } is consistent with other drivers, but the PineconeDriver import in src/drivers/index.ts:7 eagerly loads the entire pinecone.ts module at extension activation. For a cloud-only SDK unlikely to be installed on most machines, consider a lazy require() in the factory's case 'pinecone': branch (matching the lazy pattern already inside the driver itself).
  • package.json — The viewstor-pinecone icon references \\E005 in viewstor-icons.woff2, but the PR doesn't add a glyph to the font file. The icon will silently fall back to nothing until the font is updated.
  • src/drivers/pinecone.ts:233executeQuery uses parsed.params.topk || parsed.params.topK to handle case variants, but all other params are case-sensitive. Consider normalizing param keys to lowercase in the parser for consistency.

Generated by Claude Code

@Siyet Siyet added the reviewed label Apr 26, 2026
