Smile2Unlock

A modern Windows face-unlock prototype built on Credential Provider, local IPC, and SeetaFace.

Overview • Installation & Usage • Architecture • Building from Source • Screenshots • Security Notice • 简体中文

Overview

Smile2Unlock is a Windows biometric login project that experiments with a custom face-authentication flow on top of the Windows Credential Provider model.

Instead of being only a single app, the repository is organized as a small system:

• Smile2Unlock: the desktop GUI and orchestration layer
• SampleV2CredentialProvider.dll: the Windows Credential Provider integration
• FaceRecognizer: the camera, optional liveness checks, and feature extraction worker
• common: shared models, config, crypto, IPC, assets, and language resources

The current codebase already includes:

• Face capture and feature extraction
• Liveness detection via SeetaFace anti-spoofing
• A Windows login integration path through Credential Provider
• Local IPC between GUI / service / recognizer components
• An installer script for packaging and registration

Installation & Usage

For most users, the easiest way to get started is to download the pre-built installer from the Releases page.

Step 1: Download and Install

1. Go to the Releases page
2. Download the latest Smile2Unlock-Setup.exe installer
3. Run the installer with administrator privileges (required for Credential Provider registration)
4. Follow the installation wizard

Step 2: Set Up Your Face

1. After installation, launch Smile2Unlock from the Start Menu or desktop shortcut
2. Go to the Enrollment tab
3. Click "Add User" to create a new user account
4. Click "Capture Face" to enroll your facial features
5. You can enroll multiple faces for different lighting conditions or angles

Step 3: Use Face Unlock

1. Lock your Windows session (Win+L) or restart your computer
2. At the Windows login screen, you should see the Smile2Unlock credential provider tile
3. Look at your camera - the system will automatically detect your face and unlock
4. If face recognition fails, you can still use your password by clicking "Sign-in options"

Troubleshooting

• Camera not detected: Ensure your camera is properly connected and drivers are installed
• Face not recognized: Try re-enrolling your face in better lighting conditions
• Password error: Use your user password instead of PIN. If you use a Microsoft account, try entering your Microsoft account email as the username when registering in Smile2Unlock
• Credential Provider not appearing: Try rebooting or re-running the installer as administrator

Highlights

Capability	Notes
Windows login integration	Uses a custom Credential Provider DLL for Winlogon sign-in flow
Split-process design	GUI, service, and recognition worker are separated for cleaner responsibilities
Shared-memory + UDP IPC	Supports image sharing, preview streaming, probe-feature delivery, and status messaging
Local persistence	Uses SQLite plus config/runtime directories for local state
Modern C++ toolchain	Built with xmake, clang, llvm-mingw, and C++26 modules

Architecture

flowchart LR
    U[User at Windows Sign-in] --> CP[Credential Provider DLL]
    CP --> S[Smile2Unlock Service / Backend]
    S --> FR[FaceRecognizer]
    S <--> GUI[Smile2Unlock GUI]
    GUI <--> DB[(SQLite / Config / Runtime Data)]
    FR --> CAM[Camera]
    FR --> MODEL[SeetaFace Models]
    FR --> S

Loading

Sign-in flow

sequenceDiagram
    participant User
    participant CP as Credential Provider
    participant Service as Smile2Unlock Service
    participant FR as FaceRecognizer
    participant GUI as Smile2Unlock GUI

    User->>CP: Open sign-in screen
    CP->>Service: Request biometric authentication
    Service->>FR: Start capture / recognition task
    FR->>FR: Detect face, optionally run liveness checks, and extract a probe feature
    FR-->>Service: Return probe feature after capture / liveness gates pass
    Service->>Service: Compare probe feature against enrolled local features
    Service-->>CP: Approve or reject sign-in step from the service-owned match result
    GUI-->>Service: Configure device, profile, and runtime settings

Loading

Runtime roles

• SampleV2CredentialProvider.dll plugs into the Windows authentication surface.
• Smile2Unlock.exe --service acts as the privileged backend / IPC host.
• Smile2Unlock.exe without --service launches the GUI and can connect to an already-running backend.
• FaceRecognizer.exe handles camera-oriented recognition tasks such as one-shot capture, preview streaming, liveness checks, and feature extraction. The service owns login-time feature comparison and decides whether CP receives final success.

Why the project is split this way

This layout helps keep Windows sign-in integration, GUI behavior, and recognition execution relatively isolated. That makes it easier to debug the login flow, evolve the recognizer separately, and avoid tying camera-heavy logic directly into the provider DLL.

Project Structure

.
|-- Smile2Unlock/          # Main GUI app, backend service, runtime orchestration
|-- CredentialProvider/    # Windows Credential Provider DLL
|-- FaceRecognizer/        # Recognition worker, camera capture, SeetaFace integration
|-- common/                # Shared models, modules, IPC helpers, resources
|-- local-repo/            # Local xmake package repository
|-- licenses/              # Third-party license texts
|-- NOTICE/                # Third-party notices
|-- setup.iss              # Inno Setup installer script
`-- xmake.lua              # Primary build entry

Repository map

flowchart TD
    ROOT[Smile2Unlock_v2]
    ROOT --> APP[Smile2Unlock/]
    ROOT --> CP[CredentialProvider/]
    ROOT --> FR[FaceRecognizer/]
    ROOT --> COMMON[common/]
    ROOT --> BUILD[xmake.lua]
    ROOT --> INSTALLER[setup.iss]
    ROOT --> NOTICE[NOTICE/ + licenses/]

    APP --> APP1[GUI + backend orchestration]
    CP --> CP1[Windows sign-in integration]
    FR --> FR1[Camera + recognition worker]
    COMMON --> COMMON1[IPC + config + crypto + resources]

Loading

Tech Stack

• Windows Credential Provider API
• SeetaFace 6
• SQLite3
• GLFW + Dear ImGui
• Boost
• Mbed TLS
• libyuv
• xmake
• clang + llvm-mingw

Building from Source

This section is for developers and users who want to build from source. Most users should use the pre-built installer from the Releases page.

Requirements

• Windows 10 or later
• xmake
• llvm-mingw-ucrt-x86_64
• A working camera
• Administrator privileges for installation / Credential Provider registration

Build

xmake f -y -c -p mingw -a x86_64 --mingw="D:\Tools\llvm-mingw-ucrt-x86_64" --sdk="D:\Tools\llvm-mingw-ucrt-x86_64" --toolchain=clang --runtimes=c++_static
xmake require --build -f -y seetaface6open
xmake build

Build outputs

The main targets defined in xmake.lua are:

• Smile2Unlock
• FaceRecognizer
• SampleV2CredentialProvider.dll

Running locally

Launch the GUI:

.\build\mingw\x86_64\release\Smile2Unlock.exe

Launch backend service mode:

.\build\mingw\x86_64\release\Smile2Unlock.exe --service

Inspect recognizer CLI help:

.\build\mingw\x86_64\release\FaceRecognizer.exe --help

Creating an Installer

The repository includes an Inno Setup script at setup.iss that can be used to create a distributable installer. This is useful for developers who want to package their own builds:

• Build the project using the instructions above
• Run Inno Setup with setup.iss to create Smile2Unlock-Setup.exe
• The generated installer will:
  • Copy the application files
  • Deploy SampleV2CredentialProvider.dll into System32
  • Register the Credential Provider CLSID
  • Install with administrator privileges

Most users should download the pre-built installer from the Releases page instead of building their own.

Screenshots

Showcase

This section highlights the Windows login side of the project:

FaceRecognizer CLI

FaceRecognizer already exposes several useful modes:

• recognize
• capture-image
• preview-stream
• compare-features

Typical entry point:

.\FaceRecognizer.exe --mode recognize --camera 0 --liveness-detection=true

For service-launched recognition, boolean options are passed with explicit values, for example --liveness-detection=false. In the sign-in flow, recognize emits a probe feature after capture and optional liveness checks; Smile2Unlock.exe --service compares that feature with enrolled local features before forwarding final success or failure to the Credential Provider.

Status

This repository is best understood as a serious prototype / experimental system rather than a production-ready authentication product.

Areas that still deserve continued hardening include:

• deployment ergonomics
• operational logging and diagnostics
• failure recovery around camera / IPC / login edge cases
• security review and threat modeling
• test coverage for sensitive authentication paths

Security Notice

This project touches Windows authentication surfaces and processes biometric data locally. Review the code carefully before using it beyond research, experimentation, or controlled environments.

You should assume that production deployment requires:

• a dedicated security review
• credential-provider-specific validation
• anti-spoofing evaluation
• secure storage and lifecycle rules for biometric material
• rollback and recovery planning in case of failed login integrations

License

This project is licensed under the MIT License.

Third-party attributions and notices are available in:

• NOTICE/THIRD-PARTY-NOTICES.md
• licenses/

Contributing

Contributions are welcome, especially around:

• installer polish
• recognizer robustness
• documentation and diagrams
• testing and reproducible setup

If you introduce a new dependency, please keep its license and attribution information in sync with the existing notices.
