Insert images inline with text, float them, resize them — with working HTML and DOCX export.
This is a fork of ep_images_extended by DCastelone, with critical bug fixes for the HTML and DOCX export pipeline.
The original plugin stored images correctly in the pad but they were invisible in HTML and DOCX exports. Six bugs were identified and fixed:
Bug 1 — Export hooks were never registered
exportHTML.js existed but getLineHTMLForExport and stylesForExport were missing from ep.json, so the export code never ran.
Bug 2 — Text lines were broken
The export handler modified lineContent for every line, even lines with no images. This caused text lines to lose formatting and show * placeholders.
Bug 3 — Only one image per line
A break statement stopped processing after the first image on a line. Multiple side-by-side images were lost.
Bug 4 — Text alignment was lost
When ep_align was installed alongside this plugin, image lines lost their alignment because the alignment wrapper from ep_align was overwritten.
Bug 5 — DOCX export crashed
Bug 6 — Local storage images missing from exports
Images stored on disk (local storage mode) were exported as relative server paths (/static/images/...). These paths do not resolve when the HTML file is opened locally or when DOCX is generated. Fixed by fetching images from the internal server and embedding them as base64 at export time.
| Feature | v1.1.2 | v2.0.0 |
|---|---|---|
| Images visible in HTML export | ✗ | ✓ |
| Images visible in DOCX export | ✗ | ✓ |
| Local storage images in exports | ✗ | ✓ (embedded as base64) |
| Multiple images per line | ✗ | ✓ |
| Text alignment preserved | ✗ | ✓ |
| Text lines unaffected | ✗ | ✓ |
PDF export in Etherpad uses pdfkit with a built-in HTML parser that does not support images, colors, or advanced formatting from plugins. This is a core Etherpad limitation with no plugin hooks available. Images will not appear in the default PDF export.
Etherpad only (ep_etherpad-lite) — no other plugin is required; this plugin
adds image support itself. For images in PDF export specifically, also use a
real PDF exporter such as
ep_pdf_export_print or
ep_pdf_export_chromium,
since core PDF export ignores images (see the note above).
Via the Etherpad admin panel — search for ep_images_extended_v2.
Or from the command line in your Etherpad directory:
pnpm run plugins i ep_images_extended_v2
Add an ep_images_extended block to your settings.json:
| key | type | default | description |
|---|---|---|---|
fileTypes |
Array<string> | none | Allowed extensions (no dot). If omitted, any image/ MIME is accepted. |
maxFileSize |
Number (bytes) | unlimited | Reject files larger than this. |
storage |
Object | { "type": "base64" } |
Storage backend. See below. |
1. Embedded Base-64 (default — zero config)
2. Amazon S3 with presigned uploads
"ep_images_extended": {
"storage": {
"type": "s3_presigned",
"region": "us-east-1",
"bucket": "my-etherpad-images",
"publicURL": "https://cdn.example.com/",
"expires": 900
},
"fileTypes": ["png", "jpg", "webp"],
"maxFileSize": 10485760
}AWS credentials are read from environment variables (AWS_ACCESS_KEY_ID, AWS_SECRET_ACCESS_KEY).
3. Local disk
"ep_images_extended": {
"storage": {
"type": "local",
"baseFolder": "static/images",
"baseURL": "https://pad.example.com/etherpad-lite/static/images/"
},
"fileTypes": ["jpeg", "jpg", "png", "gif"],
"maxFileSize": 5000000
}Bug reports and PRs are welcome.
- Original plugin: ep_images_extended by DCastelone
- Based on: ep_image_insert by Mamy Linx, John McLear, Ilmar Türk and contributors
- Bug fixes and v2: Ivan Forkaliuk
See NOTICE.md for full attribution.
