Fix #1833: Improve transcription response format compatibility

[anditherobot]

Summary

This PR fixes #1833 for the OpenAI-compatible transcription API.

Apps can request transcription results in different formats, including JSON, plain text, SRT, and VTT. Lemonade already accepted those requests, but plain text and subtitle formats were still wrapped in JSON instead of being returned directly. That could confuse apps expecting normal text or subtitle output.

This change makes text, srt, and vtt return raw text bodies. json, verbose_json, and errors still return JSON.

Before, a vtt response looked like this:

{
  "text": "WEBVTT\n\n00:00:00.000 --> 00:00:04.000\nListen, read, repeat.\n"
}

After this change:

WEBVTT

00:00:00.000 --> 00:00:04.000
Listen, read, repeat.

The same applies to srt.

Testing

I reviewed the full diff and kept the change scoped to transcription response formats.

I manually checked the endpoint with a WAV file using all supported response formats: json, verbose_json, text, srt, and vtt. This confirmed the old behavior: text, srt, and vtt were returned as JSON wrappers.

I ran git diff --check. The commit also passed the repo pre-commit hooks, including Black.

Documentation

Updated the OpenAI API docs to list the supported transcription response formats: json, verbose_json, text, srt, and vtt.

Fixes #1833

[fl0rianr]

Thanks, good work! The transcription behavior looks right.
But there is a blocker regarding the scope of the forward_multipart_request() change. This helper is also used by SD image edits/variations, where successful responses are expected to be JSON. With this PR, any successful non-JSON response from those backends would become {"text": ...} and be returned to clients as HTTP 200 instead of surfacing as an invalid backend response. Could we make the non-JSON-success fallback opt-in and enable it only for transcription requests with response_format set to text, srt, or vtt?

I’d also add a negative test for an unsupported response_format value so the new documented supported-values list is enforced deterministically.

[ramkrishna2910]

@claude review

[github-actions]

Claude finished @ramkrishna2910's task in 2m 9s —— View job

---

Code Review: Transcription response formats (#2088)

• Read the PR diff and changed files
• Trace forward_multipart_request() callers and backend transcription paths
• Assess @fl0rianr's blocker and the requested negative test
• Post review

---

Nice fix — the user-facing behavior (text/srt/vtt returning raw bodies, json/verbose_json staying JSON) is correct and well-tested. I agree with @fl0rianr's blocker, and tracing the code actually makes the case stronger. Details below.

🔴 Blocker: the wrapped_server.cpp change is broader than transcription — and not even needed for whisper

The change at src/cpp/server/wrapped_server.cpp:196-201 adds a non-JSON→{"text": ...} fallback to the shared forward_multipart_request() helper. Its callers are:

Caller	Endpoint	Expected 200 body
whisper_server.cpp	—	does not use this helper (see below)
fastflowlm_server.cpp:398	/v1/audio/transcriptions	text or JSON ✅ intended
sd_server.cpp:540	/v1/images/edits	JSON ❌ side effect
sd_server.cpp:573	/v1/images/edits (variations)	JSON ❌ side effect

For SD image edits/variations, a malformed non-JSON 200 previously surfaced as a backend error (the json::parse throw was caught at wrapped_server.cpp:221 → NetworkException). With this change it silently becomes {"text": "<garbage>"} returned as HTTP 200 — exactly the regression @fl0rianr flagged.

Crucially, the whisper.cpp backend doesn't go through this helper at all — WhisperServer does its own post_multipart + parse and already wraps non-JSON itself at whisper_server.cpp:557-563:

try {
    return json::parse(res.body);
} catch (const json::parse_error&) {
    return json{{"text", res.body}};   // already handled here
}

So the only transcription backend that benefits from the forward_multipart_request() change is FastFlowLM, while the cost is changed semantics for SD.

Recommended fix (cleanest, matches existing convention): revert the wrapped_server.cpp change and instead do the try/parse/wrap locally in fastflowlm_server.cpp:398, mirroring exactly what whisper_server.cpp already does. This scopes the fallback to the one backend that needs it and leaves SD's strict-JSON contract intact — no opt-in flag needed.

// fastflowlm_server.cpp, replacing line 398
auto resp = forward_multipart_request("/v1/audio/transcriptions", fields);
// FLM returns raw text for text/srt/vtt; the helper already wrapped it as {"text": ...}
return resp;

If you'd rather keep it in the shared helper, the alternative is an opt-in bool allow_raw_text_fallback = false param (default preserves SD behavior, transcription callers pass true) — that also satisfies the blocker, but duplicating the whisper pattern in FLM is more consistent with the codebase.

Fix this →

🟡 Negative test needs server-side validation to be deterministic

@fl0rianr also asked for a negative test for an unsupported response_format. Note that there is currently no validation of response_format in handle_audio_transcriptions — an unsupported value (e.g. "foo") is just forwarded to the backend, whose behavior (error vs. default-to-json) isn't guaranteed. So a negative test today wouldn't be deterministic.

To enforce the newly-documented supported-values list, add a check in server.cpp (around server.cpp:2182, before forwarding) that returns HTTP 400 with an invalid_request_error for any response_format not in {json, verbose_json, text, srt, vtt}. Then the negative test can assert 400.

🟢 Minor / nits

• server.cpp:2188 — guarding on response["text"].is_string() is good defensive code; if text is somehow missing it correctly falls through to the JSON dump. 👍
• The new early-return inside the if (response.contains("error")) block (server.cpp:2174-2178) is a correct cleanup of the prior fall-through. 👍
• Content-Type text/plain for srt/vtt matches OpenAI's behavior. 👍
• Out of scope, but worth a glance: sd_server.cpp:540 and :573 both forward to /v1/images/edits — if :573 is the variations path, that may be a separate latent bug. Not part of this PR.

Test coverage

test_002b_transcription_response_formats is a solid positive test across all five formats. Once validation lands, please add the negative case @fl0rianr requested. Note this test requires a live whisper/FLM backend, so I couldn't execute it in this environment — the analysis above is from reading the code paths.

Overall: behavior is right, the docs update is accurate, but the shared-helper change should be narrowed to transcription before merge.
• fix/1833-audio-transcription-response-formats

[anditherobot]

@fl0rianr @ramkrishna2910 thanks for the reviews. I updated the PR based on the feedback.

The main issue was that the first version allowed plain text responses too broadly. That was okay for audio
transcription, but it could make image backend errors look like successful responses.

I changed it so:

• Image requests still expect proper JSON responses.
• Audio transcription can return plain text only when the user asks for text, srt, or vtt.
• Unsupported transcription formats now get a clear 400 error instead of being passed through to the backend.
• I added a test for an unsupported format.

In terms of files, the shared multipart helper is now strict by default, FastFlowLM and Whisper only allow plain
text for transcription formats that expect it, and the public transcription endpoint now rejects unsupported
formats early(good performance).

The follow-up triggered by @ramkrishna2910 was useful too: it confirmed that the same helper function is used by
both audio and image requests. I used the suggested opt-in approach, so plain text is now allowed only for audio
transcription.

Verification:

• Commit hooks passed.
• Existing tests for the supported formats are still included.
• Added the unsupported-format test.

[fl0rianr]

CI error is related:

FAIL: test_002b_transcription_response_formats (__main__.WhisperTests) (response_format='verbose_json')
Test audio transcription response_format handling.
----------------------------------------------------------------------
Traceback (most recent call last):
  File "C:\Users\user\actions-runner\_work\lemonade\lemonade\test\server_whisper.py", line 246, in test_002b_transcription_response_formats
    self.assertIn("segments", result)
AssertionError: 'segments' not found in {'model': 'whisper-v3:turbo', 'text': ' And so, my fellow Americans, ask not what your country can do for you ask what you can do for your country.'}

----------------------------------------------------------------------
Ran 3 tests in 14.913s

FAILED (failures=1)

[jeremyfowers]

@anditherobot please get CI healthy or close the PR (nothing personal just putting messages like this any PR of this age)

[anditherobot]

@jeremyfowers Thanks for following up I completely understand. The branch is now updated with the latest main
@fl0rianr Please review when you are able ..

Thank you both

[fl0rianr]

Thanks for updating and rebasing this. I re-reviewed the current head. My original two requests are addressed: the shared multipart fallback is now opt-in, and unsupported response_format values are rejected with a 400 and covered by a test.

I still see two issues before I can approve:

1. Raw text is still detected by JSON parse failure

Both WrappedServer::forward_multipart_request() and the Whisper paths first try json::parse(body) and only treat the response as raw text if parsing fails.

That is not safe for response_format=text. A perfectly valid transcript such as true, null, or 123 is also valid JSON. In that case parsing succeeds, the expected {"text": ...} wrapper is never created, and handle_audio_transcriptions() falls back to returning JSON instead of the requested raw text.

The requested format should determine how a successful response is interpreted, e.g.:

if (allow_plain_text_success) {
    return json{{"text", response.body}};
}
return json::parse(response.body);

The same applies to the Whisper paths. A small regression test with a JSON-looking text body such as true\n would cover this nicely.

2. FLM does not actually provide SRT/VTT responses

I traced the current FastFlowLM implementation as well. Its /v1/audio/transcriptions endpoint only copies model and file from the multipart request; response_format is not passed to the ASR handler. The handler always returns the compact {model, text} JSON response.

Lemonade can turn that into plain text, but it cannot produce real SRT or VTT from it. The current test masks this by skipping the --> / WEBVTT assertions when wrapped_server == "flm", so ordinary transcript text can pass as successful srt or vtt.

I think we should either reject/document those formats as unsupported for FLM, or implement actual format support. The test should not report SRT/VTT support without validating the requested format. The same limitation also explains why FLM's verbose_json response is only the compact shape.

One small bonus of fixing Nr. 1 by branching on the requested format before parsing is that the strict multipart path can keep its previous JSON parse-error behavior instead of changing error semantics for unrelated callers.

Once these two points are addressed this looks good from my side.

[anditherobot]

@fl0rianr commit 8d2ca74 covers both points.

First: the format now decides how the body is read, before anything is
parsed audio_types.h::interpret_transcription_body().

Second: dropped allow_plain_text_success FLM always returns
{model, text} JSON, so it could never fire correctly. wrapped_server.{h,cpp}
now match main exactly. FLM rejects srt/vtt with a 400, and
expect_subtitle_markup is gone.

response_format	whisper.cpp	FLM
json	JSON	JSON
verbose_json	JSON	JSON, no segments
text	text/plain -- And so my fellow Americans…	same
srt / vtt	text/plain -- 00:00:00,000 --> 00:00:07,010 etc.........	400
anything else	400 --Unsupported response_format: xml	400

[fl0rianr]

LGTM
