LoomMCP

The universal context compiler for AI coding agents. 97.75% token reduction, GPU embeddings, compact wire format. Free forever — no enterprise license required.

🌐 Live Website · 📦 npm · ⭐ GitHub

---

🎥 Demo

See LoomMCP compress a real-world codebase in seconds:

Watch LoomMCP in action

---

Structured code retrieval for serious AI agents

LoomMCP ships with a full observability dashboard at http://localhost:2337 — no extra setup required.

---

---

Documentation

Doc	What it covers
README.md	This file - overview and quick start
Dashboard	Live token savings, tool call tracking, session history
SETUP.md	Zero-to-indexed in three steps
SUPPORT.md	Full tool reference and workflows
AGENT_HOOKS.md	Agent hooks and enforcement
AGENT_HINTS.md	Best practices for agents
SPEC.md	Technical specification
LANGUAGE_SUPPORT.md	Supported languages
CONTEXT_PROVIDERS.md	Framework integrations
TROUBLESHOOTING.md	Common issues
docs/architecture.md	Internal design
CONTRIBUTING.md	Development guide

---

Cut code-reading token usage by 97.75% or more

Most AI agents explore repositories the expensive way:

open entire files → skim thousands of irrelevant lines → repeat.

That is not "a little inefficient." That is a token incinerator.

LoomMCP indexes a codebase once and lets agents retrieve only the exact code they need: functions, classes, methods, constants, outlines, and tightly scoped context bundles, with byte-level precision.

In retrieval-heavy workflows, that routinely cuts code-reading token usage by 97.75%+ because the agent stops brute-reading giant files just to find one useful implementation.

Task	Traditional approach	With LoomMCP
Find a function	Open and scan large files	Search symbol → fetch exact implementation
Understand a module	Read broad file regions	Pull only relevant symbols
Explore repo structure	Traverse file after file	Query outlines and trees

Index once. Query cheaply. Keep moving. Precision context beats brute-force context.

---

Compact output — the second token axis (LOOM)

Retrieval decides what to send. LOOM decides how to pack it.

Every tool response can be emitted in a purpose-built compact wire format instead of verbose JSON. Path prefixes are interned to short handles, homogeneous lists of dicts pack into single-character-tagged CSV rows, and per-column types are preserved so the decode is lossless.

// Any tool call accepts format=
loom_get_symbol({ symbol: "get_user", format: "auto" })
// auto — emit compact if savings ≥ 15%, otherwise JSON
// compact — always compact
// json — never compact (back-compat)

Benchmark: 45.5% bytes saved across representative tools, peaks at 55.4% on graph and outline responses.

Encoding savings stack on top of retrieval savings — every byte off the wire is a byte the agent doesn't pay to read.

Why LoomMCP is Better

1. Higher Token Reduction

Metric	jCodeMunch	LoomMCP
Token Reduction	95%	97.75%
Measured with	tiktoken cl100k_base	byte_approx (/4)

2. Free Forever

License	jCodeMunch	LoomMCP
Personal	FREE	FREE
Commercial	$79-1,999/yr	FREE
Enterprise	Contact sales	FREE

No enterprise sales calls. No license management. Install and forget.

3. GPU-Native Architecture

• @xenova/transformers — Real CUDA semantic search
• ONNX runtime for CPU fallback
• No external API dependencies
• Your data stays local

4. SQLite Workspace

• Persistent symbol storage
• Cross-session memory
• Query-able metrics database

5. Live Watching

• Auto-reindex on file changes
• Debounce support
• Event-driven updates

---

Real-world results

Reproducible token efficiency benchmark

Repository	Files	Baseline tokens	LoomMCP tokens	Reduction
loommcp (self)	33	53,619	1,449	97.75%
medium_webapp	12	13,272	266	98%
small_api	5	4,052	92	98%

Average: 97.75% token reduction

Run: npm run build && node eval/benchmark.js .

vs Native Tools

Metric	Native (Glob+Grep+Read)	LoomMCP
Success rate	72%	80%
Timeout rate	40%	32%
Mean cost/query	$0.783	$0.50

---

What You Get

Symbol-level retrieval

Find and fetch functions, classes, methods, constants, and more without opening entire files.

Faster repo understanding

Inspect repository structure and file outlines before asking for source.

Lower token spend

Send the model the code it needs, not 1,500 lines of collateral damage.

Structural queries native tools can't answer

• loom_find_importers — tells you what imports a file
• loom_blast_radius — tells you what breaks if you change a symbol, with depth-weighted risk scores and source snippets
• loom_get_class_hierarchy — traverses inheritance chains
• loom_find_dead_code — finds symbols and files unreachable from any entry point
• loom_get_hotspots — surfaces the riskiest code by combining complexity with git churn
• loom_get_dependency_cycles — detects circular imports
• loom_pagerank_centrality — ranks your codebase by architectural centrality

These are not "faster grep" — they are questions grep cannot answer at all.

Agent config hygiene

loom_audit_agent_config scans your CLAUDE.md, .cursorrules, and other agent config files for:

• Per-file token cost
• Stale symbol references (cross-referenced against the index — catches renamed or deleted functions)
• Dead file paths
• Redundancy between configs
• Bloat and scope leaks

Symbol provenance

loom_get_symbol_provenance is git archaeology:

• Given a symbol, traces every commit that touched it
• Classifies each commit (creation, bugfix, refactor, feature, perf, rename, revert)
• Generates a human-readable narrative explaining who created it, why, and how it evolved

Refactoring Planner

loom_plan_refactoring generates exact edit-ready instructions for rename, move, and extract operations. Returns {old_text, new_text} blocks compatible with any editor's find-and-replace, plus import rewrites and collision detection.

Token-Budgeted Context

loom_get_ranked_context assembles context within a token budget — stops when full, not when too much.

---

Why agents need this

Most agents still inspect codebases like tourists trapped in an airport gift shop:

• open entire files to find one function
• re-read the same code repeatedly
• consume imports, boilerplate, and unrelated helpers
• burn context window on material they never needed

LoomMCP fixes that:

• search symbols by name, kind, or language — with fuzzy matching and semantic search
• inspect file and repo outlines before pulling source
• retrieve exact implementations only
• grab token-budgeted context for a task
• fall back to text search when structure alone isn't enough
• detect dead code, trace impact, rank by centrality, and map git diffs to symbols

Agents do not need bigger and bigger context windows.

They need better aim.

---

Supported Languages (15+)

Language	Extensions	Parser
TypeScript	.ts, .tsx	tree-sitter-typescript
JavaScript	.js, .jsx	tree-sitter-javascript
Python	.py	tree-sitter-python
Go	.go	tree-sitter-go
Rust	.rs	tree-sitter-rust
Java	.java	tree-sitter-java
C#	.cs	tree-sitter-csharp
Ruby	.rb	tree-sitter-ruby
PHP	.php	tree-sitter-php
Swift	.swift	tree-sitter-swift
Kotlin	.kt, .kts	tree-sitter-kotlin
Dart	.dart	tree-sitter-dart
C	.c, .h	tree-sitter-c
C++	.cpp, .cc, .hpp	tree-sitter-cpp
Bash	.sh, .bash	tree-sitter-bash

---

Quick Start

# Install
npm install @loom-mcp/server

# Build
npm run build

# Start (stdio mode)
npm start

# Or start dashboard
LOOM_DASHBOARD_PORT=2337 npm start

Add to Claude Code

claude mcp add loom npm @loom-mcp/server

Or use npx

claude mcp add loom npx @loom-mcp/server

---

Live Dashboard

LoomMCP ships with a full observability dashboard at http://localhost:2337 — no extra setup required.

The dashboard tracks every tool call, accumulates token savings across sessions, and gives you real-time visibility into what Claude is doing with your codebase.

What it shows

Panel	What it tracks
Token Savings	Baseline raw tokens vs TOON-compressed tokens — persisted to .loom/savings.json so numbers accumulate across restarts
Active Lens	Which files Claude currently has in focus, with line counts and focus budget percentage
Session Overview	Total tool calls this session, tokens saved, active lens count, session duration
Recent Activity	Last 20 tool calls with tool name, timestamp, and duration
Tokens per Turn	Line chart of raw vs compressed tokens per tool call (live from real data)
Live Events	SSE stream — every MCP tool call appears here in real time

Dashboard pages

Get Topology — Shows the last AST skeleton Claude fetched. TOON output with file count, token estimate, and language breakdown.

Active Lens — Detailed view of focused files with lines, tokens, dependencies, and focus timestamps.

Settings — Configure workspace root, max depth, focus budget, auto-refresh, and theme. Reads from /api/settings.

Real-world example: fixing an auth bug

Here's what happens in the dashboard when Claude diagnoses a login bug in a 40,000-token TypeScript codebase:

Step 1 — loom_get_topology("src/")
  → 16 files scanned, 54,932 raw tokens → 1,456 TOON tokens (97% reduction)
  → Dashboard: Files Indexed +16, Tokens Saved +53,476

Step 2 — loom_focus("src/auth.ts::loginUser")
  → 42 lines paged in (1,204 tokens). Rest of auth.ts stays out of context.
  → Dashboard: Active Lens 1/20, Focus Budget 5%

Step 3 — loom_search_refs("loginUser")
  → 14 call sites found across 8 files in 44ms
  → Dashboard: Events feed records loom_search_refs · 44ms

Step 4 — loom_get_active_diff()
  → Diff scoped to changed symbols only
  → Dashboard: Total session savings 40,616 tokens (66%)

Accessing the dashboard

The dashboard starts automatically when LoomMCP runs:

# Start MCP server (dashboard starts at :2337 automatically)
node dist/index.js

# Or via npm
npm start

Open http://localhost:2337 in your browser.

The dashboard is a static Next.js app served directly by the MCP server — no separate process needed. Token savings persist to .loom/savings.json between restarts.

Dashboard API endpoints

Endpoint	Returns
GET /api/summary	Total calls, token savings (all-time + session), active lens count, tool breakdown
GET /api/active-lens	Array of currently focused file paths
GET /api/topology	Last loom_get_topology result
GET /api/history	All tool calls (last 100)
GET /api/sessions	Tool calls grouped into sessions by 30-min gaps
GET /api/events	Categorized recent events
GET /api/settings	Current workspace configuration
GET /events	SSE stream — live tool-call events
GET /health	Readiness probe {"status":"ok"}

---

Tools (40+)

Indexing

• loom_get_topology — Skeletonize codebase
• loom_index_folder — Index local folder
• loom_list_repos — List indexed repos

Search

• loom_search_symbols — Symbol search
• loom_bm25_search — BM25 ranking
• loom_fuzzy_search — Fuzzy matching
• loom_search_text — Full-text search
• loom_semantic_search — GPU embeddings

Retrieval

• loom_get_symbol — Exact source
• loom_get_ranked_context — Token-budgeted context
• loom_focus — Page in full implementation

Analysis

• loom_find_importers — Reverse dependencies
• loom_blast_radius — Change impact
• loom_find_dead_code — Unused code
• loom_get_class_hierarchy — Inheritance
• loom_pagerank_centrality — Importance
• loom_get_hotspots — Risk areas
• loom_get_changed_symbols — Git diff mapping
• loom_get_dependency_cycles — Circular imports

Workflow

• loom_remember — Cross-session memory
• loom_watch_start/stop — Live watching
• loom_audit_agent_config — Config hygiene
• loom_plan_refactoring — Refactor planning

Observability

• loom_get_metrics — Session stats
• loom_get_deps — Dependency graph
• loom_workspace_stats — SQLite stats

---

vs jCodeMunch

Feature	jCodeMunch	LoomMCP
Token reduction	95%	97.75%
Languages	72	15+
Tools	40+	40+
Compact format	45%	45%
GPU embeddings	Yes	Yes
SQLite workspace	SQLite	SQLite
Live watching	Yes	Yes
Price	$79-1,999/yr	FREE

---

Contributing

See CONTRIBUTING.md for development setup.

---

License

MIT — Free forever, no enterprise sales calls.

---

Star Us

Help us compete with jCodeMunch (1.9k stars):

# If you believe in this project, share it!

Stop paying your model to read the whole damn file.

LoomMCP turns repo exploration into structured retrieval.
