Examples - Update

[NickHardeman]

Some of the examples could be removed or refreshed / updated.
Below are some that I think could use some attention and I plan to update.
Will submit a PR per example.

3d

• 3d / cameraRibbonExample Update camera ribbon example to use radians and polylines for smoothing #7103
• 3d / meshFromCameraExample ( spins too fast ). Map degrees to radians for glm conversion #7091
• 3d / ofNodeExample Truck with OF logo in the bed moving around #7086
• 3d / quaternionArcballExample Quaternion Arcball example update with multiple methods for deriving position #7090
• 3d / quaternionLatLongExample Example quaternion lat long example #7089
• 3d / paths to mesh example Paths to mesh example from font #7109
• 3d / better assimp example ( depends on some assimp updates @ofTheo is doing )
• 3d / switch 3dModelLoader to use assimp and better models Fixes for some model rotations and cache camera orbit on mouse press … #7382

communication

• communication / serialExample Update to the serial example  #7101

gl

• gl / alphaMaskingShaderExample ( remove, duplicate of shader / 07_fboAlphaMask) Removed because it was a duplicate of shader / 07_fboAlphaMask #7087
• gl / areaLightExample Update area light example with of logo #7078
• gl / geometryShaderExample Geometry example update with openGL3 shader support #7085
• gl / multiTextureShaderExample Example multi texture3d #7108
• gl / singleLightExample > change to gl/pointLightExample Changed singleLightExample to pointLightsExample and update #7080
• gl / transformFeedbackExample ( not included in OSX download? ) Point sprite render shader #7095
• add animated transform feedback example to gl / transformFeedbackExampleAnimated Transform Feedback animated example #7094
• add drawing into a high res fbo for high res image output Simple example of high resolution saving of an fbo #7104
• gl / shadows Update to shadows example #7308
• gl / PBR example PBR Material example #7225

shader

• shader / 07_fboAlphaMask Update to examples/shader/07_fboAlphaMask #7081

computer vision

• object detection with yolo5 Examples: OpenCV image classification example using Yolo5 #7099
• people detection Examples: opencv people detection example #7100
• optical flow Optical flow example #7112

Thoughts on any other examples?

[dimitre]

Great @NickHardeman!
One example I really wanted to change is serialExample. It can be more inviting for beginners to work with serial communication, withtout memset, memcpy etc.

[NickHardeman]

@dimitre oh yeah!
I'll add it to the list.
I haven't done serial communication in a while. Maybe someone can help out with that one ;)

[dimitre]

I can work in an alternative approach, I use something like this

void ofApp::setup(){
	int baud = 9600;
	serial.listDevices();
	vector <ofSerialDeviceInfo> deviceList = serial.getDeviceList();
	// this should be set to whatever com port your serial device is connected to.
	// (ie, COM4 on a pc, /dev/tty.... on linux, /dev/tty... on a mac)
	// arduino users check in arduino app....
	serial.setup(0, baud); //open the first device
}

void ofApp::update(){
	if (serial.available()) {
		serial.readBytes(buffer, serial.available());
		serialData += buffer.getText();
		serial.flush();
	}
}

[NickHardeman]

That definitely seems more approachable.

[ofTheo]

Going to ping @ofZach @lingdong @golanlevin on this thread and see if there are any examples that students often ask for.

[ofZach]

I'll think about this, but off the top of my head, some demos my students always really appreciate:

• drawing into a high res fbo for high res image output
• examples that help explain how to do custom meshes / geometry and texture map them (ie, cut up a webcam into triangles, etc)
• converting paths -> polylines, polylines to meshes, etc

also if useful, @lingdong made this recently -- https://docs.google.com/spreadsheets/u/1/d/1cY0y377O5_fCWIJpXBNPofY-CCQq942r-sAb6SwKhkI/edit#gid=0 -- about conversions between different raster formats.... maybe some demo ideas there?

[ofZach]

other things that may be cool --

• using offset shader (using a grain texture to add noise to drawing)
• texture feedback with shader (ie, ping ponging fbos and pushing colors via a shader)

[ofTheo]

Thanks @ofZach these are great! 👍

Been thinking that we should maybe just integrate the FBO read back from: https://github.com/satoruhiga/ofxFastFboReader into ofFbo.

The code is quite minimal and it would allow for realtime read back of high res FBOs.

converting paths -> polylines, polylines to meshes, etc

Oh this would be a great one!!

thanks!!

[dimitre]

Edit: updated in this PR - #7119
videoGrabber, maybe change resolution to 640x480 once macOS doesn't support 320x240 anymore in builtin webcam

[NickHardeman]

Thank you for the insight @ofZach :) I added a few examples based on some of your suggestions

drawing into a high res fbo for high res image output

Simple saving of high res fbo #7104

converting paths -> polylines, polylines to meshes, etc

Paths to meshes from font #7109

[NickHardeman]

I can work in an alternative approach, I use something like this

void ofApp::setup(){
	int baud = 9600;
	serial.listDevices();
	vector <ofSerialDeviceInfo> deviceList = serial.getDeviceList();
	// this should be set to whatever com port your serial device is connected to.
	// (ie, COM4 on a pc, /dev/tty.... on linux, /dev/tty... on a mac)
	// arduino users check in arduino app....
	serial.setup(0, baud); //open the first device
}

void ofApp::update(){
	if (serial.available()) {
		serial.readBytes(buffer, serial.available());
		serialData += buffer.getText();
		serial.flush();
	}
}

@dimitre see #7101 :)

[ofTheo]

@ofZach - some thoughts on fbo readback here.
Found an approach that seems faster than the ofxFastFboReader addon.

#7111

[eduardfrigola]

Hi @NickHardeman
Thanks for those great examples!
Regarding the transformFeedbackExample I think is safe to include it in macos download right? I saw you build the examples using that platform.

The removal of the example from the downloads in macos, is before we merged the fix for transform feedback in macos. #6473

So I think after the fix we could include it in macos download.

[NickHardeman]

@eduardfrigola yes I created the example on macOS 12.5.1 with M1 chip. So it should be good to go on macOS

[NickHardeman]

@eduardfrigola thank you! I had been doing transform feedback with all GL calls prior to making this example and discovered that it had been integrated into OF. It's really great. Makes it much more straight forward.
