feat: delegation token cache

[terylt]

Summary

Every delegate step runs an RFC 8693 exchange. A token valid for five minutes is used once and discarded, which puts an IdP round trip on every delegated call and makes the IdP a dependency of every request rather than of every few minutes.

This lets the OAuth delegator reuse a token it already minted. Off by default; a cache: block turns it on.

Closes #30.

Cache Key

The key is an HMAC-SHA256 over 14 length-prefixed components under a per-process secret. The load-bearing component is the credential being exchanged, not security.subject.id:

• A derived identity is only as good as the claim map that produced it, and feat: configurable claim mapping for the JWT identity plugin #31 has just made that map operator-editable.
• Two principals cannot present the same credential unless one holds the other's, at which point the cache is not what went wrong.
• fast-jwt shipped an identity-derived key and it became GHSA-rp9m-7r4c-75qg at CVSS 9.1. Its default key, the token itself, was never affected.

Excluded deliberately: security.subject.id for the reasons above, and AgentExtension.agent_id, which is caller-settable session state rather than a credential.

Refused outright, so the delegation falls back to minting: an empty credential on a subject that should carry one, a route with an unrendered resource_template (a handler may one day render request arguments into it), and any #[non_exhaustive] variant this build does not recognise.

Behavior

• Off by default. With no cache: block the delegator runs the code it ran before.
• Subject-gated. Enabling covers this_workload and client only. Their entry count is bounded by configuration; user and caller_workload grow with the caller population and are opt-in through cache.subjects.
• Coalesced. N concurrent requests for one uncached key produce one exchange rather than N.
• Bounded, with LRU eviction, since a caller able to vary a key component can create entries.
• A failed exchange is never stored.
• Two clocks. Entries retire on a monotonic clock, and every read is also checked against the token's own wall-clock expiry, because Instant does not advance across a host suspend.
• Staleness is a fraction of lifetime plus a floor and jitter, not a fixed margin. A fixed margin larger than a short token's lifetime gives a permanent zero percent hit rate that still looks like a working cache.

A cached token stays usable after an IdP-side revocation until its entry retires. cache.ttl_ceiling_seconds is the bound.

Also here: a config-load warning when a route has a delegate step that exchanges the caller's credential but resolves no identity for it, since identity: is per-route and optional.

Not in this PR

• A mint rate limit. Reaching the delegator implies identity resolution has validated the credential, so the amplification concern is narrower than feat(delegator-oauth): cache delegated tokens until expiry #30 assumed. What remains is hardening rather than a fix.

• A sweep for expired entries independent of eviction pressure, so an expired entry holds its slot until something touches it.

• A weigher. The bound counts entries, not bytes.

• Any way to clear the cache on demand. The revocation window above is bounded by cache.ttl_ceiling_seconds but cannot be ended early. A flush() exists on the store and is tested, but nothing is wired to it. Restarting the process or reloading config drops the cache as a side effect, since load_config builds fresh plugin instances.

  Worth knowing before revocation support is designed: the key is an HMAC of the credential, so an event carrying the revoked token can be turned back into the exact keys to invalidate. An event naming only a subject cannot, because subject.id is deliberately not in the key, and would need either a secondary index or a full flush. Checking revocation by introspection on the read path would put back the round trip the cache removes.

• Any cross-process tier. The cache and its coalescing are per process, so N proxies cold on one key produce N exchanges.

Testing

104 tests. The load-bearing one is two_callers_are_never_handed_each_others_token, driven through the handler against a mock IdP with both mocks matching on subject_token, so it also checks the delegator sent the right credential for each caller. Removing the credential from the key derivation fails that test and only that test.

concurrent_requests_for_one_key_mint_once runs 16 tasks through a barrier on a multi-threaded runtime and asserts exactly one exchange.

The handler's trait signature is unchanged, which is why the 23 pre-existing delegator e2e tests pass untouched.

Dependencies

hmac and sha2 for the key (sha2 was already vendored, so hmac adds one crate and nothing transitive; blake3 would have brought a new tree for a speed advantage that does not matter at one hash per delegation). moka for the store, which adds five crates and supplies the coalescing and never-cache-an-error guarantees that would otherwise be hand-rolled here. All permissive licences.

[praxis-bot]

Review Summary

Thorough, well-reasoned work. The cache-key derivation is carefully anchored on the credential rather than the identity, with clear documentation of why and references to real CVEs that got this wrong. The dual-clock strategy (monotonic for TTL, wall-clock for token expiry) handles the host-suspend edge case correctly. The coalescing guarantee via moka is well-motivated, the NotCacheable enum is a clean way to refuse caching with diagnostics, and the test suite is strong — particularly two_callers_are_never_handed_each_others_token and the concurrency test.

One medium finding on config validation below.

[praxis-bot]

[Medium] validate() checks floor_seconds >= ttl_ceiling_seconds but does not account for jitter_seconds pushing the margin past the ceiling for a fraction of entries.

Example: floor_seconds: 250, jitter_seconds: 100, ttl_ceiling_seconds: 300 passes validation because 250 < 300. But serve_window() computes margin = max(fraction * 300, 250) + (jitter_byte / 255) * 100 = 250 + 0..100, giving a window of 300 − (250..350) = −50..50. For roughly half the entries (those with jitter_byte > ~127) the window is zero or negative, so they are minted but never served from cache. The runtime warned_unservable latch catches this per-token, but only after traffic arrives — the same class of silent-zero-hit-rate configuration the existing floor >= ceiling check was designed to prevent at startup.

Add a check after the existing floor >= ceiling guard:

if self.staleness.floor_seconds.saturating_add(self.staleness.jitter_seconds)
    >= self.ttl_ceiling_seconds
{
    return Err(format!(
        "cache.staleness.floor_seconds ({}) + cache.staleness.jitter_seconds ({}) \
         is at or above cache.ttl_ceiling_seconds ({}), so most entries would be \
         stale before they could be served",
        self.staleness.floor_seconds,
        self.staleness.jitter_seconds,
        self.ttl_ceiling_seconds
    ));
}

[araujof]

Nice work! This will be a great performance improvement for delegation flows.

I found two issues to address before merging:

• In cache/store.rs, the wall-clock check only considers the token's expiry. After a system suspend, it can serve a token beyond ttl_ceiling_seconds, defeating the documented revocation limit. It should also check minted_at + serve_for.
• The identity warning is described as a config-load warning, but RouteDispatchPlan is built on the first request. A bad route therefore loads without warning. This check should run during config loading.

The existing tests pass, but a focused test reproduces the expiry issue.

[terylt]

Updated based on @araujof comments.

[araujof]

LGTM
